10.2" Open Frame
Touch Panel Computer
10.2 inch Dual Core Touch Panel  ATS-M1000DA10W
ATS-M1000 Series touch panel computers are low-heat, low-power, high-performance systems. More of all, durability is excellent. And then, Autobase SCADA CE Software has been pre-installed by default.

*Reference Document

Ease of development-Windows CE embedded touch panel computer
Windows Compact 7(CE 7.0) OS is installed by default, so it is easy for software engineers to develop and deploy, using Visual Studio 2008/2004 (language C# .Net/Basic .Net/C++).

*View more details
Economical system configuration! Autobase SCADA CE preloaded!
SCADA Softwares are high price but ATS-M1000 Series touch panels come with Autobase SCADA CE and which can help you configure systems economically. Even if you have not Visual studio or any other database program, you can develop systems using Autobase SCADA CE for automation fields, high-tech industry, medical devices and etc.. Especially, we have developed vast amounts of communication drivers and which are offered free.

*View more details
High-performance 1GHz Dual Core CPU
The ARM® Cortex®-A9 processor is the power-efficient and popular high performance choice in low power or thermally constrained cost-sensitive devices.
Maintaining Water and Dust Resistance
Front Water-resistant and dustproof based on IP65 rating. So it is suitable for humid environments and can be used in an unsafe industrial sites from the liquid.
Customized product manufacturing
Autobase provides customized automation solution and user-specific touch panels. For this, we adapt our products with the modifications necessary to satisfy your requirements: from minor design changes right to OEM-hardware and software systems.
Specifications
Display 10.2inch (16:9, 800x480)
CPU Cortex-A9 Dual 1,000MHz
Memory DRAM 512MB DDR3, NAND Flash 512MB
(Option : DRAM 1GB DDR3, NAND Flash 1GB)
Serial Port 4 Ports (RS-232C 3 Ports, RS-485/232C 1 Port)
USB USB Host 2 Ports, USB Device 1 Port
HDMI 1 Port
Extension Port GPIO(16EA), PWM(2ch), A/D Converter(4ch)
Audio Speaker, Audio Out(Stereo Earphone Jack)
Ethernet 1 Port (Gigabit)
SD Card 1 Slot(SDHC up to 32GB, SDXC up to 2TB)
Touch Screen 4-wire resistive
Voltage DC 9~24V
Power consumption 7W
Dimension(mm) 284(H)*179(V)*53.7(D)
Waterproof IP65
Operating Temperature -10~70˚C
OS Windows Compact 7 (CE7)
